Automating Godot 4 Android Exports with GitHub Actions (II)

In Part 1 of this guide, we successfully set up Godot 4 in a GitHub Actions Ubuntu runner, matched our dynamic export templates, and learned how to “pre-heat” the .godot/ cache to prevent headless crashes.

Now, it’s time to face keystores and complete workflow. Passing security credentials safely through a CI/CD pipeline and publishing the final .aab file can be a nightmare of cryptic errors. Here is how to do it perfectly.

Preparing your Release Keystore

GitHub Secrets can’t store binary files directly. You need to convert your .keystore to a Base64 text string. Run this in your terminal:

base64 -w 0 your_android_release.keystore > keystore_b64.txt

Go to your GitHub repository settings (Settings > Secrets and variables > Actions) and add these three secrets:

• ANDROID_GP_KEYSTORE_BASE64: The contents of the text file.
• ANDROID_GP_KEYSTORE_PASSWORD: Your keystore password.
• ANDROID_GP_KEYALIAS_NAME: Your keystore alias.

The Complete Workflow

Add the permissions block at the top of your job, and append these final steps to the YAML file we started in Part 1:

    # VITAL: Grants the action permission to upload the .aab to the Release page
    permissions:
      contents: write

      # ... (Previous steps from Part 1) ...

      - name: Decode and Validate Keystore
        env:
          KEYSTORE_BASE64: ${{ secrets.ANDROID_GP_KEYSTORE_BASE64 }}
          KEYSTORE_PASSWORD: ${{ secrets.ANDROID_GP_KEYSTORE_PASSWORD }}
          KEYALIAS_NAME: ${{ secrets.ANDROID_GP_KEYALIAS_NAME }}
        run: |
          mkdir -p ~/.android
          echo "$KEYSTORE_BASE64" | base64 --decode > ~/.android/google_play.keystore

          echo "Validating Keystore..."
          # Fail-fast: If the password or alias is wrong, the workflow stops here immediately.
          keytool -list -v -keystore ~/.android/google_play.keystore -alias "$KEYALIAS_NAME" -storepass "$KEYSTORE_PASSWORD" | grep "Alias name:"

      - name: Export Release
        env:
          # https://docs.godotengine.org/en/stable/tutorials/export/exporting_for_android.html
          # IMPORTANT: Use an absolute path. YAML does not expand the '~' character!
          GODOT_ANDROID_KEYSTORE_RELEASE_PATH: /home/runner/.android/google_play.keystore
          GODOT_ANDROID_KEYSTORE_RELEASE_USER: ${{ secrets.ANDROID_GP_KEYALIAS_NAME }}
          GODOT_ANDROID_KEYSTORE_RELEASE_PASSWORD: ${{ secrets.ANDROID_GP_KEYSTORE_PASSWORD }}
        run: |
          # Pre-heating step
          echo "Generating asset cache (.godot/)..."
          godot --headless --editor --quit || true

          echo "Installing Android Build Template and compiling the game..."
          mkdir -p build/android
          godot --headless --verbose --install-android-build-template --export-release "Android - Google Play" "build/android/${{ github.event.repository.name }}_${{ github.ref_name }}.aab"

      - name: Create GitHub Release
        uses: softprops/action-gh-release@v2
        with:
          files: build/android/${{ github.event.repository.name }}_${{ github.ref_name }}.aab
          name: Android - Google Play ${{ github.ref_name }}
          generate_release_notes: true

1. The “Fail-Fast” Validation Debugging Godot export errors takes minutes. If you made a typo in your Keystore password, you won’t know until the end. By adding the native Java keytool validation piped with grep "Alias name:", we create a strict security guard. If your Base64 string is corrupted or the password is wrong, the workflow fails instantly, saving you time.

2. The Tilde (~) Trap Godot 4 allows you to pass Keystore credentials using environment variables. However, if you assign ~/.android/google_play.keystore to GODOT_ANDROID_KEYSTORE_RELEASE_PATH, it will fail. YAML does not expand the ~ shortcut like Bash does. Godot will literally look for a folder named ~, fail, and throw a “Release keystore incorrectly configured” error. You must always use the absolute path (/home/runner/...).

3. Repository Permissions If you don’t explicitly add permissions: contents: write at the top of your job, the final step will fail with a Resource not accessible by integration error, and your .aab will never be uploaded.

Gist

@pazalla

Conclusion

The next time you push a version tag, GitHub will spin up a machine, configure Godot, securely inject your credentials, compile the Gradle build, and attach a pristine .aab file right to your Releases page! No manual exports, just pure automation.

Furthermore, having this optimized workflow is vital to maximize the free compilation time provided by GitHub Actions. Currently, GitHub gives every free account 2,000 free minutes per month for private repositories (if your project is open-source/public, it’s completely unlimited!).

Since our Android export uses a Linux machine (ubuntu-latest), 1 real-time minute of compilation equals exactly 1 minute of your quota. With our guide, your .aab will build extremely fast, leaving you with plenty of minutes to spare.

🛑 What about iOS? A quick warning

If you plan to adapt this workflow for iOS in the future, you must use an Apple virtual machine (macos-latest). However, macOS runners on GitHub Actions have a 10x multiplier. This means that 1 real minute of iOS compilation consumes 10 minutes of your free quota.

In other words, your 2,000 monthly minutes translate to just 200 real minutes of iOS build time. This is exactly why optimizing your CI/CD pipeline and preventing endless headless crashes isn’t just a convenience—it’s a necessity to avoid burning through your monthly limit!
